ARES Electrical 是一款电气项目开发软件，其内置多项自动化功能以辅助项目各阶段工作
x64 | 文件大小: 730 MB
功能描述
ARES Electrical 是一款电气项目开发软件，内置专为辅助项目各阶段工作设计的自动化功能，可显著加速重复性流程。
核心特性
该软件配备组件向导工具，可创建带自动引用功能的电气项目。其资料库包含预制注册组件符号，支持直接插入图纸方案。
如何在电气柜构建中应用AE？
用户可通过完全可定制的元件库注册系统管理组件，支持设置自动化命名、技术参数描述、功能说明、制造商数据和内部编码。此外，还可注册子电路模块（如电机启动器子电路），便于集成到大型项目中。
AE提供自动化生成功能，可输出材料清单（BOM）、线缆表、端子表和标签数据，在保障数据准确性的同时大幅提升设计效率。
AE项目如何辅助控制面板配置？
基于AE开发的项目可提供全流程指导——从元件选型与参数规范，到线管尺寸规划与元件布局，乃至线缆路径优化与设备互联设计。
系统配备智能布线清单功能，可精确显示线缆接续节点与路径派生，数字化预装配可将实际安装误差降至最低。线长计算支持自定义余量设置，有效避免线材短缺。
系统需求
操作系统：Windows 10 或更高版本
处理器：Intel Core i5、AMD Athlon/Phenom™ x4 或更优芯片
存储空间：至少1GB可用硬盘空间（视插件安装情况）
内存：8GB RAM
显卡：支持OpenGL 3.2以上的3D图形加速卡
显示器：Full HD分辨率
外设：滚轮鼠标或3D鼠标
ARES Electrical 是一款用于开发电气项目的软件，它具有多种自动化功能，可协助项目的各个阶段
x64 | File Size: 730 MB
Description
ARES Electrical is a software for the development of electrical projects, which has several automations created to assist in the various stages of a project, especially speeding up repetitive processes.
Description
ARES Electrical is a software for the development of electrical projects, which has several automations created to assist in the various stages of a project, especially speeding up repetitive processes.
How can AE help me build an electrical enclosure?
For the creation of an electrical project with automatic references, there is a component wizard. AE has a library with several representations already registered, ready to be inserted in a scheme.
The library register is completely customizable, and may contain automatic names, technical descriptions, functions, manufacturer and internal code. In addition, it is possible to register sub-circuits, that are, circuits that will integrate a larger project, such as a motor starter sub-circuit drawing, for example.
The AE also has features that automatically generate bill of materials lists used, cables/wires, terminals and tags, providing important information, avoiding manual errors and greatly speeding up the design process.
What do AE projects help me with when setting up a control panel?
The projects developed in the AE follow the assembly technician from the bill of materials lists and specification of the components, predicting the length of wires and size of the ducts, to the positioning of the components, the paths that the wires will travel and the connection between the items.
When assembling a control panel, there are several aspects to be considered, including safety and waste of wires and cables. With the wiring list generated in AE, we will know where the wire derives or connects, thus bringing a much smaller margin of error in circuit assembly digitally before put hands on. In addition, it is possible to customize an additional margin when calculating the length of the cables, avoiding cable insufficiency.
System requriements
OS:Windows 10 or higher
CPU:Intel Core i5 processor, AMD Athlon/Phenom™ x4 processor, or better
Space:1 GB free hard disk space depending on accessory applications installed
Memory:8 GB RAM
GPU:3D Graphics accelerator card with OpenGL version 3.2 or better
Display:Full HD monitor
Hardware:Wheel mouse, or 3D mouse
