CFTurbo 是一款专业的叶轮机械设计软件。 CFturbo软件结合了成熟的旋转机械理论与丰富的实践经验，基于理论方程与经验函数库，广泛应用于泵、风扇、鼓风机、压缩机、涡轮等的整机设计，包括转子、导叶、扩压器、蜗壳等部件。
文件大小: 318 MB
CFTurbo是一款功能强大且易于使用的泵设计软件，既可从头设计泵体，亦可对现有叶轮进行重新设计。只需输入流量、扬程、转速和（可选）预旋参数，CFTurbo即可自动生成泵设计方案。随后用户可在软件指导下对设计细节进行任意修改。这种灵活高效的泵设计方法既可节省时间，又能确保获得理想的泵体设计。
3D CAD模型功能
动态三维呈现(旋转、平移、缩放)
高度可定制的局部视图
CAD模型导出
现有几何体导入对比
参数化几何模型
所有设计阶段参数可导出
可为参数变化设定范围限制
轻松集成优化工作流程或实验设计(DoE)研究
逆向工程
基于现有几何体开展优化设计
子午面曲线自动转为贝塞尔样条导入功能
基于前后缘给定叶片角或现有中弧线进行叶片设计
叶片厚度分布输入/导入功能
IGES/STEP数据导入与再设计3D模型对比
子午面设计
部件子午面预览
快速访问设计步骤
部件接口处理
激活部件选择
显示截面面积、流速、流动角度等参数变化曲线
项目管理
设计信息管理
带设计状态回溯功能的设计报告
特定参数警告提示
关键设计细节展示
数据导出
支持点、曲线、曲面、实体导出
通用格式接口(STEP/IGES/STL/DXF)
主流CAD/CFD系统接口
按需定制专用接口
性能预测
显示不同转速和叶轮直径性能曲线
基于经验公式计算叶轮基本损失
CFTurbo 是一款专业的叶轮机械设计软件。 CFturbo软件结合了成熟的旋转机械理论与丰富的实践经验，基于理论方程与经验函数库，广泛应用于泵、风扇、鼓风机、压缩机、涡轮等的整机设计，包括转子、导叶、扩压器、蜗壳等部件。
File size: 318 MB
CFTurbo is powerful, yet easy to use, pump design software that can help you design pumps from scratch or redesign existing impellers. Simply tell it the flow rate, head, RPM, and any (optional) pre-swirl and CFTurbo will automatically generate a pump design. You then have the option of going back and changing any details of the design with CFTurbo’s guidance. This easy, but flexible, approach to pump design saves you time and still lets you get exactly the pump design you want.
3D CAD model
Dynamic 3D-representation (rotate, move, zoom)
Highly configurable partial views
Export of CAD model
Import of existing geometry for comparison
Parametric geometry model
Properties of all design steps available as parameters
Parametrics can be exported
Optionally, range limits can be specified for parameter variations
Eeasy integration into optimization workflows or DoE inverstigations
Reverse Engineering
Redesign of existing geometry as starting point for optimization
Import of existing meridional curves with automated conversion to Bezier splines
Blade design based on given blade angles on leading and trailing edge or import existing meanline curves
Input or import of blade thickness distribution (blade profiles)
Comparison of imported IGES/ STEP data with the redesigned 3D model
Meridian
Meridional preview of project components
Quick access to design steps
Handling interfaces between components
Select active component
Show progressions for area, velocity, flow angle
Project management
Management of project information
Design report with the option of restoring previous design status
Display of warnings regarding specific parameters
Display of key design details
Data export
Export of points, curves, surfaces, solids
Neutral interfaces (STEP, IGES, STL, DXF)
Interfaces to important CAD and CFD systems
Implementation of special interfaces on customer request
Performance prediction
Display of performance curves for different rotational speed and impeller diameters
Calculation of fundamental impeller losses based on empirical correlations
