BRIGADE/Plus为各类桥梁与土木结构建模提供了一个直观易用环境。其用户界面集成了建模、分析和结果可视化功能。基于参数化特征的概念使复杂结构建模更高效。
该软件包含符合多种设计规范（含欧洲规范及其各国附录）的预定义荷载、车辆和荷载组合。
BRIGADE/Plus提供瞬态/稳态动态分析、非线性材料模型、接触相互作用等先进功能。结果可通过3D图表和2D图形直观呈现，内置报告生成器可高效创建输入/成果文档，并支持自动导出至ConcreteDesigner配筋模块或用户自有的配筋设计工具。
x64 | 文件大小: 3.60 GB
产品描述
BRIGADE/Plus是为所有类型桥梁和土木结构提供建模解决方案的易用平台，通过参数化特征建模技术实现复杂结构的高效建模。
易用建模环境
直观界面支持任意类型桥梁及土木结构建模。
建模概念
基于参数化特征的技术实现复杂几何快速建模。
完整分析流程
涵盖静力学、传热学、动力学及耦合分析。
移动荷载分析
行业领先的移动荷载响应评估技术。
移动荷载动态响应
高效分析移动荷载动力学特性。
预应力分析
支持预应力体系全过程分析。
荷载组合
先进荷载组合模块自动考虑规范要求。
分部施工模拟
通过在分析过程中增/删结构部件、荷载及边界条件实现分段施工模拟。
非线性材料特性
支持材料非线性行为定义。
稳健接触算法
配备可靠的接触模拟功能。
数据可视化
提供丰富的后处理模块进行成果解读。
报告生成器
自动生成输入参数与计算结果报告。
配筋设计
通过ConcreteDesigner模块实现欧标配筋计算。
Abaqus求解内核
集成达索系统SIMULIA的Abaqus有限元求解器。
脚本功能
全面支持Python二次开发。
分析能力范畴
静力学
– 线性/非线性静力响应
– 特征值屈曲
– 失稳崩溃与后屈曲分析
传热分析
– 瞬态传热分析
– 稳态传热分析
动力学
– 固有频率提取
– 模态动态时程分析
– 隐式动态时程分析（线性/非线性）
– 稳态动态响应
– 反应谱分析
– 随机振动分析
耦合分析
– 顺序热-应力耦合分析
系统需求
操作系统：适用于Windows Server 2008 R2 SP1 / Windows 8.1 / Server 2012 R2 / Windows 10
最低配置：
处理器：Intel x86-64架构
内存：16GB RAM
显卡：100% OpenGL兼容显卡
存储空间：30GB可用空间
高端工作站推荐配置：
处理器：双路Intel至强可扩展处理器（Skylake架构）
内存：每CPU配置32-64GB
显卡：NVIDIA Quadro专业图形卡
存储：推荐500GB以上机械硬盘，固态硬盘可选用但不强制要求
BRIGADE/Plus为所有类型的桥梁和土木结构建模提供了一个易于使用的环境。直观的用户界面集成了建模、分析和结果可视化。参数化、基于特征的概念使复杂结构的建模变得高效。
我们的软件包括预定义的荷载、车辆和荷载组合，符合广泛的设计规范，包括带有各种国家附件的欧洲规范。
BRIGADE/Plus提供一系列先进的功能，如瞬态和稳态动态分析、非线性材料模型和接触相互作用。结果很容易在3D图和2D图中可视化。集成报告生成器可用于有效创建输入报告和结果报告。结果可以自动导出到钢筋模块ConcreteDesigner或客户自己的钢筋设计工具。
x64 | File Size: 3.60 GB
Description
BRIGADE/Plus provides an easy-to-use environment for modeling of all types of bridges and civil structures. The intuitive user-interface integrates modeling, analysis and visualization of results. The parametric, feature-based, concept enables efficient modelling of complex structures.
Our software includes predefined loads, vehicles and load combinations in accordance with a wide range of design codes including the Eurocodes with various National Annexes.
BRIGADE/Plus offers a complete range of advanced capabilities such as transient- and steady state dynamic analysis, non-linear material models and contact interactions. The results are easily visualized in 3D plots and 2D graphs. The integrated report generator can be used for efficient creation of input and result reports. Results can be automatically exported to the reinforcement module ConcreteDesigner or to customers own tool for design of reinforcement.
Easy-to-use Modeling Environment
Easy-to-use environment for modeling of any type of bridge & civil structure.
Modeling Concept
Parametric, feature-based, concept enabling fast and simple modeling of complex geometries.
Complete Set of Analysis Procedures
Including static, heat transfer, dynamic & coupled.
Moving Loads
Market-leading technique for evaluation of the response of moving loads.
Dynamic Response of Moving Loads
Efficient analysis of the dynamic response of moving loads.
Prestressing
BRIGADE/Plus allows for the analyses of prestressing.
Load Combination
State-of-the-art load combination facility automatically taking into account.
Segmental Construction
Analyze the effect of segmental construction by adding and removing parts of the structure, loads, boundary condition etc. during analysis.
Non-linear Material Behaviour
BRIGADE/Plus offers the possibility to include non-linear material behavior.
Robust Contact Capabilities
BRIGADE/Plus offers a robust contact capability.
Result Visualization
Wide range of post-processing features in order to enable efficient interpretation of results.
Report Generator
BRIGADE/Plus includes generators for automatic generation of input and result reports.
Reinforcement Design
Reinforcement in accordance with Eurocode can easily be calculated using the module ConcreteDesigner.
Integrated Abaqus Solver Technology
BRIGADE/Plus includes an integrated Abaqus FEA solver from SIMULIA.
Scripting Functionality
BRIGADE/Plus makes extensive use of Python.
BRIGADE/Plus provides a vast range of analysis procedures
Static
-Linear and nonlinear static response
-Eigenvalue buckling
-Unstable collapse and post buckling
Heat transfer
-Transient heat transfer analysis
-Steady-state heat transfer analysis
Dynamic
-Natural frequency extraction
-Modal dynamic time history
-Implicit dynamic time history (linear & nonlinear)
-Steady-state dynamic response
-Response spectrum
-Random response
Coupled
-Sequentially coupled thermal-stress analysis
System Requirements
OS:Server 2008 R2 SP1 / Windows 8.1 / Server 2012 R2 / Windows 10
Minimum requirement
CPU:Intel x86-64processor
Memory:16GB RAM
GPU:100% OpenGL compatible graphics card
Storage:30GB of free disk space
High end server/ workstation recommendation
CPU:Dual Intel Xeon Scalable (also known as “Skylake” ) processor
Memory:32– 64 GB per CPU
GPU:NVIDIA Quadro series card dedicated to CAD/CAE applications
Storage:At least 500GB hard disk drive/SSDs may be used, but are not necessary for good simulation performance
