Proteus软件是英国Lab Center Electronics公司出版的EDA工具软件。它不仅具有其它EDA工具软件的仿真功能,还能仿真单片机及外围器件。它是目前较好的仿真单片机及外围器件的工具。虽然目前国内推广刚起步,但已受到单片机爱好者、从事单片机教学的教师、致力于单片机开发应用的科技工作者的青睐。
文件大小:594 MB
功能说明:
Proteus是用于电路计算机辅助设计的软件套件。该系统基于PSpice采用的电子元件模型进行电路仿真。Proteus Professional 套件的显著特点是能够模拟可编程设备的工作:微控制器、微处理器、DSP等元件。此外,该套件还包含PCB设计系统,支持模拟8051、ARM7、AVR、Motorola、PIC、Basic Stamp等微控制器,元件库包含完整的参考数据。
支持处理器:PIC、8051、AVR、HC11、MSP430、ARM7/LPC2000及其他常见处理器。包含超过6,000个模拟和数字设备模型。兼容主流编译器和汇编器。PROTEUS VSM能够可靠实现包含多个微控制器甚至跨家族混合系统的复杂设备仿真。附加说明:安装指南详见readme.txt,已在Debian 9系统wine-3.0.3环境下通过32位WINEPREFIX测试,运行稳定性优于8.8版本(旧版存在项目保存问题)。
系统需求:
操作系统:微软Windows XP或更高版本(推荐64位Windows 7及以上)
处理器:2GHz或更快Intel处理器(AMD处理器可用但优化不足)
显卡:支持OpenGL 2.0和/或Direct 3D并具备多重采样(MSAA)功能
内存:3GB RAM(推荐8GB)
注意:请以管理员权限运行安装程序和应用程序!
File Size: 594 MB
Description:
Proteus is a software package for computer-aided design of electronic circuits. The package is a system of circuit simulation based on models of electronic components adopted in PSpice. A distinctive feature of the Proteus Professional package is the ability to simulate the operation of programmable devices: microcontrollers, microprocessors, DSP, and more. Additionally, the Proteus package includes a PCB design system. Proteus Professional can simulate the following microcontrollers: 8051, ARM7,AVR,Motorola, PIC, Basic Stamp. The component library contains reference data.
Supports MK: PIC, 8051, AVR, HC11, MSP430, ARM7 / LPC2000 and other common processors. Over 6,000 analog and digital device models. Works with most compiler and assembler.PROTEUS VSM allows you to very reliably simulate and debug quite complex devices that can contain several MKs simultaneously and even different families in one device! Add. Information : Installation instructions in readme.txt Performance tested in wine-3.0.3 on Debian 9 with 32-bit WINEPREFIX. It works more stably than 8.8 (there were problems with saving projects)
System Requirements:
OS:Microsoft Windows XP or later (recommended Microsoft Windows 7 64 bit or later)
CPU:2GHz or faster Intel processor (AMD processors fine but less optimized)
GPU:Graphics card supporting OpenGL Version 2.0 or higher and / or Direct 3D and multi-sampling (MSAA).
Memory:3GB RAM (recommended 8GB)
Note:Run Setup and application with adminstrator Rights.!
